Graco Reactor 2 H-40

Code: 17H043
(replaces #253400 & 253401)
$45,210.00
Low Inventory item. Shipments arrive daily. Place your order and we will contact you with availability.

Qty

17H043 - R2 REACTOR H-40, HYD, 230V, 15KW

TECHNICAL SPECIFICATIONS:

Max Tip Size: 04 mix chamber

Max GPM (LPM): 45 lbs per min

Max PSI (BAR): 2000 psi

Engine: Hydraulic Driven

Noise Level: 82.6 db

Maximum Hydraulic Pressure: 1000 psi

Fluid Inlet: 3/4" Iso and Resin

Fluid Outlet: #5 JIC, #6 JIC

Hose Connection: #5 JIC, #6 JIC

Hydraulic Reservoir Capacity: 3.5 gal Iso Grade 46

Dimensions: 32.96"L x 20.88"w x 63.3"h x 600lbs

Generator Minimum Wattage: 40kw

Power Requirements: 3 phase 230 volt @71 amp

Cycles: 0.063 cycles per mixed gallon A&B

Make all your part and quantity selections, then click any "Add and Go to Cart" button when completed.

247786 TRANSFORMER KIT, 5400VA, 410 FT

247786 - TRANSFORMER KIT, 5400VA, 410 FT

Price: $3,550.00 ea.

247826 HYDRAULIC RESERVOIR ASY

247826 - HYDRAULIC RESERVOIR ASY

Price: $1,425.00 ea.

255019 HYDRAULIC PUMP KIT

255019 - HYDRAULIC PUMP KIT

Price: $3,100.00 ea.

803889 BELT (H-25) **

803889 - BELT (H-25) **

Price: $25.60 ea.

296607 5944 CLEVIS PIN EXTRACTOR

296607 - 5944 CLEVIS PIN EXTRACTOR

Price: $58.00 ea.

24K207 FTS KIT, RTD, SINGLE HOSE

24K207 - FTS KIT, RTD, SINGLE HOSE

Price: $585.00 ea.



296731 15585/15586 LUBE RESERVOIR HOSE ASY

296731 - 15585/15586 LUBE RESERVOIR HOSE ASY

Price: $163.50 ea.

206995 THROAT SEAL LIQUID, 1 QT (REF - 117)

206995 - THROAT SEAL LIQUID, 1 QT (REF - 117)

Price: $46.50 ea.

24K240 HOSE, RTD,BLUE SCUFF, 2000 PSI, 3/8, 50', E-30i & R2 - NO CAN

24K240 - HOSE, RTD,BLUE SCUFF, 2000 PSI, 3/8, 50', E-30i & R2 - NO CAN

Price: $2,490.00 ea.

246050 1250E-PL/1250D-PL WHIP-1/4" X 10 FT. W/SCUFF GUARD (LOW PRESSURE WHIP - 2000 PSI)

246050 - 1250E-PL/1250D-PL WHIP-1/4" X 10 FT. W/SCUFF GUARD (LOW PRESSURE WHIP - 2000 PSI)

Price: $0.00 ea.

247812 TRANSFORMER KIT, 4090 VA, 230/90

247812 - TRANSFORMER KIT, 4090 VA, 230/90

Price: $2,960.00 ea.

247816 KIT, MOTOR, 230 VAC, 4.0 HP (H-25/HXP-2)

247816 - KIT, MOTOR, 230 VAC, 4.0 HP (H-25/HXP-2)

Price: $2,190.00 ea.



247792 KIT, FLTR, OIL, 18-23 PSI BYPASS ..(H-25/H-30/H-40)

247792 - KIT, FLTR, OIL, 18-23 PSI BYPASS ..(H-25/H-30/H-40)

Price: $63.75 ea.

24U854 MODULE KIT, GCA, ADM, REACTOR 2

24U854 - MODULE KIT, GCA, ADM, REACTOR 2

Price: $975.00 ea.

15V551 SHIELD MEMBRANE, ADM **

15V551 - SHIELD MEMBRANE, ADM **

Price: $17.40 ea.

112793 PACKING O-RING **

112793 - PACKING O-RING **

Price: $4.80 ea.

120299 HYDRAULIC DIRECTIONAL VALVE

120299 - HYDRAULIC DIRECTIONAL VALVE

Price: $692.00 ea.

296653 15515 CLEVIS PIN

296653 - 15515 CLEVIS PIN

Price: $129.50 ea.



121312 ELBOW FITTING, MA, 3/4 SAE X 1/2 JIC (REF - 814)

121312 - ELBOW FITTING, MA, 3/4 SAE X 1/2 JIC (REF - 814)

Price: $12.00 ea.

295225 0576 PIPE PLUG

295225 - 0576 PIPE PLUG

Price: $6.65 ea.

106258 PACKING O-RING

106258 - PACKING O-RING

Price: $8.15 ea.

295229 9489 GREASE FITTING

295229 - 9489 GREASE FITTING

Price: $3.75 ea.

295829 5484A-4 POLYETHYLENE PIPE PLUG

295829 - 5484A-4 POLYETHYLENE PIPE PLUG

Price: $10.40 ea.

295826 1484-3 FITTING, MALE ELBOW

295826 - 1484-3 FITTING, MALE ELBOW

Price: $15.10 ea.



295397 5484-3 LUBE HOSE FITTING

295397 - 5484-3 LUBE HOSE FITTING

Price: $29.70 ea.

121319 FITTING, ADAPTER, 1/2 NPT X 1/2 JIC

121319 - FITTING, ADAPTER, 1/2 NPT X 1/2 JIC

Price: $9.90 ea.

121309 FITTING, CONN, 3/4 SAE X 1/2 JIC (REF - 303)

121309 - FITTING, CONN, 3/4 SAE X 1/2 JIC (REF - 303)

Price: $6.80 ea.

295029 RETAINER PLATE

295029 - RETAINER PLATE

Price: $100.50 ea.

295030 1501B-10-4 CYLINDER BODY

295030 - 1501B-10-4 CYLINDER BODY

Price: $301.00 ea.

295031 1501B-10-7 ROD BUSHING

295031 - 1501B-10-7 ROD BUSHING

Price: $115.00 ea.



296642 1501B-10-10 PISTON ASSEMBLY

296642 - 1501B-10-10 PISTON ASSEMBLY

Price: $749.00 ea.

295640 1501B-11-1 O-RING

295640 - 1501B-11-1 O-RING

Price: $3.40 ea.

295641 1501B-11-2 U-CUP

295641 - 1501B-11-2 U-CUP

Price: $13.80 ea.

295642 1501B-11-3 BACK UP RING

295642 - 1501B-11-3 BACK UP RING

Price: $8.45 ea.

296643 1501B-11-4 TEFLON GLASS WEAR RING

296643 - 1501B-11-4 TEFLON GLASS WEAR RING

Price: $105.50 ea.

158776 1501B-11-6 PACKING, O-RING **

158776 - 1501B-11-6 PACKING, O-RING **

Price: $18.40 ea.



295644 1501B-11-7 BACK UP RING

295644 - 1501B-11-7 BACK UP RING

Price: $3.75 ea.

295645 1501B-11-8 ROD WIPER

295645 - 1501B-11-8 ROD WIPER

Price: $8.15 ea.

295032 15511-1 PROP PUMP SPACER

295032 - 15511-1 PROP PUMP SPACER

Price: $78.50 ea.

261502 REVERSING SWITCH SPACER

261502 - REVERSING SWITCH SPACER

Price: $91.75 ea.

295034 15511-3 HYD CYL TIE ROD

295034 - 15511-3 HYD CYL TIE ROD

Price: $51.00 ea.

295035 42501-1-1 PORT BLOCK

295035 - 42501-1-1 PORT BLOCK

Price: $245.00 ea.



177156 0135-024 PACKING, O-RING

177156 - 0135-024 PACKING, O-RING

Price: $6.80 ea.

295852 15527 JAM NUT/BAFFLE (H40)

295852 - 15527 JAM NUT/BAFFLE (H40)

Price: $79.75 ea.

247824 VALVE, DRAIN, CARTRIDGE (REF - 802)

247824 - VALVE, DRAIN, CARTRIDGE (REF - 802)

Price: $375.00 ea.

158674 1701-13A-2 PACKING, O-RING (REF - 802a)

158674 - 1701-13A-2 PACKING, O-RING (REF - 802a)

Price: $13.20 ea.

247779 KIT, SEAL, SEAT, VALVE (REF - 802b)

247779 - KIT, SEAL, SEAT, VALVE (REF - 802b)

Price: $58.75 ea.

102814 6314-13/296816 GAUGE, PRESSURE, FLUID, 0-5000 PSI (REF - 803)***

102814 - 6314-13/296816 GAUGE, PRESSURE, FLUID, 0-5000 PSI (REF - 803)***

Price: $0.00 ea.



162453 FITTING, NIPPLE ** (REF - 804)

162453 - FITTING, NIPPLE ** (REF - 804)

Price: $23.60 ea.

15M669 SENSOR, PRESSURE, FLUID OUTLET

15M669 - SENSOR, PRESSURE, FLUID OUTLET

Price: $907.00 ea.

247788 HANDLE, LEFT, RED, ISO (REF - 806)

247788 - HANDLE, LEFT, RED, ISO (REF - 806)

Price: $39.70 ea.

247789 HANDLE, RIGHT, BLUE, RESIN (REF - 807)

247789 - HANDLE, RIGHT, BLUE, RESIN (REF - 807)

Price: $39.70 ea.

112309 NUT, HEX, JAM (REF - 808)**

112309 - NUT, HEX, JAM (REF - 808)**

Price: $5.40 ea.

100840 FITTING, ELBOW, STREET (REF - 815)**

100840 - FITTING, ELBOW, STREET (REF - 815)**

Price: $18.50 ea.



111457 PACKING, O-RING (REF - 816)

111457 - PACKING, O-RING (REF - 816)

Price: $14.50 ea.

150829 SPRING, COMPRESSION (REF - 818)**

150829 - SPRING, COMPRESSION (REF - 818)**

Price: $9.70 ea.

117557 5330-4 HOSE ELBOW (REF - 813)

117557 - 5330-4 HOSE ELBOW (REF - 813)

Price: $18.60 ea.

255149 DRAIN VALVE REPAIR KIT, ISO (REF - )

255149 - DRAIN VALVE REPAIR KIT, ISO (REF - )

Price: $407.00 ea.

255150 DRAIN VALVE REPAIR KIT, RESIN (REF - )

255150 - DRAIN VALVE REPAIR KIT, RESIN (REF - )

Price: $407.00 ea.

255148 DRAIN VALVE SET (REF - )

255148 - DRAIN VALVE SET (REF - )

Price: $782.00 ea.



124132 O-RING (REF - 315)

124132 - O-RING (REF - 315)

Price: $2.90 ea.

15H305 PLUG FITTING, HH, 1-3/16 (REF - 313)

15H305 - PLUG FITTING, HH, 1-3/16 (REF - 313)

Price: $20.20 ea.

15H302 REDUCER FITTING, 1-3/16 X 1/2

15H302 - REDUCER FITTING, 1-3/16 X 1/2

Price: $37.90 ea.

15H306 ADAPTER THERMOCOUPLE (REF - 305)

15H306 - ADAPTER THERMOCOUPLE (REF - 305)

Price: $88.50 ea.

120336 PACKING O-RING (REF - 306)

120336 - PACKING O-RING (REF - 306)

Price: $12.10 ea.

16A110 HEATER ROD, IMMERSION, (2550W,230V) (REF - 307)

16A110 - HEATER ROD, IMMERSION, (2550W,230V) (REF - 307)

Price: $473.00 ea.



15B137 SWITCH, OVER TEMP. (REF - 308)

15B137 - SWITCH, OVER TEMP. (REF - 308)

Price: $66.25 ea.

15B135 MIXER IMMERSION HEATER (REF - 309)

15B135 - MIXER IMMERSION HEATER (REF - 309)

Price: $47.90 ea.

123325 COMPRESSION FITTING, 1/8 NPT, SS

123325 - COMPRESSION FITTING, 1/8 NPT, SS

Price: $58.75 ea.

118459 1433A-3 FITTING, SWIVEL UNION (REF - 65f)

118459 - 1433A-3 FITTING, SWIVEL UNION (REF - 65f)

Price: $18.70 ea.

-C20487 HEX NIPPLE ** (REF - 65d)

-C20487 - HEX NIPPLE ** (REF - 65d)

Price: $23.20 ea.

180199 FILTER, REPLACEMENT 20 MESH (REF - 65c)

180199 - FILTER, REPLACEMENT 20 MESH (REF - 65c)

Price: $49.50 ea.



128061 PACKING O-RING, FX75

128061 - PACKING O-RING, FX75

Price: $36.80 ea.

16V879 FILTER CAP

16V879 - FILTER CAP

Price: $80.65 ea.

15D757 THERMOMETER HOUSING, VISC. HP

15D757 - THERMOMETER HOUSING, VISC. HP

Price: $79.75 ea.

109077 VALVE, BALL, 3/4"** (REF - 65e)

109077 - VALVE, BALL, 3/4"** (REF - 65e)

Price: $126.50 ea.

253481 GUARD GAUGE, WYE STRAINER

253481 - GUARD GAUGE, WYE STRAINER

Price: $37.90 ea.

24U855 KIT, TC MODULE,GCA,MZHP,REACTOR2

24U855 - KIT, TC MODULE,GCA,MZHP,REACTOR2

Price: $899.00 ea.



24Y263 MODULE KIT, GCA, HCM

24Y263 - MODULE KIT, GCA, HCM

Price: $673.00 ea.

24R736 DISCONNECT SWITCH, DOOR MOUNTED

24R736 - DISCONNECT SWITCH, DOOR MOUNTED

Price: $459.00 ea.

123967 KNOB (REQUIRES NEW SWITCH) (REF - 34)

123967 - KNOB (REQUIRES NEW SWITCH) (REF - 34)

Price: $84.25 ea.

16U530 R2 SURGE PROTECTOR

16U530 - R2 SURGE PROTECTOR

Price: $112.50 ea.

255022 RELAY CONTACTOR KIT, 65A, 3P

255022 - RELAY CONTACTOR KIT, 65A, 3P

Price: $298.00 ea.

255043 KIT, HOLDER, FUSE, TER BLK, 5X20MM

255043 - KIT, HOLDER, FUSE, TER BLK, 5X20MM

Price: $107.50 ea.



247581 CYLINDER SEAL KIT, 140

247581 - CYLINDER SEAL KIT, 140

Price: $595.00 ea.

247579 PISTON SEAL KIT, 140

247579 - PISTON SEAL KIT, 140

Price: $595.00 ea.

24L973 KIT, HEATER RTD

24L973 - KIT, HEATER RTD

Price: $593.00 ea.
