Graco E-20 Reactor 3 Pro Package 7kw
Code: ISR311
$32,300.00
ISR311 - REACTOR 3 E-20 PRO TIER SPRAY FOAM PROPORTIONER PACKAGE, 50FT INTERNAL HEATED HOSE, 7KW
TECHNICAL SPECIFICATIONS:
Max Tip Size: 02
Max GPM (LPM): 20lbs min.
Max PSI (BAR): 2000 PSI
Includes: Reactor 3 E-20 7kw Pro, 50ft internal heated hose, 20' internal heated whip
Fluid Inlet: 3/4" npt
Hose Connection: JIC
Dimensions: 56.5"h x 24.9"w x 15"d x 260lbs.
Generator Minimum Wattage: 20KW
Power Requirements: 220 volt @ 56A 1 phase, 36A 3 phase
