PMC Mach 2 Dual Hose Foam Machine
Processing...

PMC Mach 2 Dual Hose Foam Machine

Code: 203767

$68,850.00

Low Inventory item. Shipments arrive daily. Place your order and we will contact you with availability.

Qty

203767 - M2, 5HP, 220V, 3PH, RV, 120T, 18KW


TECHNICAL SPECIFICATIONS:

Max Tip Size: Supports up to two 02 or equivalent size chambers

Max GPM (LPM): 40 lbs/min

Max PSI (BAR): 2000 PSI, 190 degrees F

Engine: Hydraulic

Includes: Bare machine 18KW dual heaters

Fluid Inlet: 3/4" npt

Hose Connection: 5 JIC Iso, 6 JIC Resin

Hydraulic Reservoir Capacity: 16 gallons

Dimensions: 40"W x 30"D x 55"H x 864 lbs full of hydraulic oil

Generator Minimum Wattage: 40kw

Power Requirements: 77 amp @ 230v 3 phase
